Below-grade expansion joint waterproofing: A starter guide for designers

The piece highlights the importance of proper product selection, redundancy, and maintenance planning for below-grade expansion joints, providing guidance to mitigate water intrusion risks and enhance infrastructure longevity.
Sept. 8, 2025
6 min read

This article was authored by Esper Chao, PE, Project Consultant, Simpson Gumpertz & Heger; and Justin deWolfe, PE, Associate Principal, Simpson Gumpertz & Heger.

Structural engineers often require below-grade expansion joints to accommodate the independent movement of adjacent elements such as basement foundations, tunnels, parking garages, or utility vaults. Unlike above-grade systems, below-grade waterproofing and expansion joint design faces higher risks of water intrusion due to hydrostatic pressure, soil movement, and runoff conditions. Because these systems are buried behind concrete and soil, repairs are costly and disruptive, making early planning and proper product selection essential.

This article explores the factors influencing below-grade expansion joint waterproofing design, compares common system options, and offers best practices for architects, engineers, and contractors to mitigate common expansion joint constructability issues.

Understanding Site Conditions

The first step in below-grade waterproofing design is understanding groundwater and soil pressures of the project site. Foundations built below the water table are exposed to significant hydrostatic forces, which vary by location and season. Determining the design water table elevation requires a geotechnical report that details soil properties, groundwater conditions, and potential settlement.

Recommendations from the geotechnical report—such as foundation drainage systems, settlement allowances, and waterproofing strategies—should be integrated into the overall expansion joint design. Also, based on the site soil pressures, provide adequate structural protection behind the expansion joint gap, to resist soil pressure while still allowing for movement.

Structural Engineering Considerations

Because expansion joints are primarily a structural requirement, coordination with the structural engineer is critical. Key questions to resolve early in design include:

  • How much movement is anticipated (horizontal, vertical, and shear)?

  • What is the expected gap width, and will joint fillers be used?

  • Can the below-grade expansion joint be eliminated altogether if movement is negligible?

If the joint can be eliminated and the foundation doweled together, the waterproofing design becomes far simpler and leakage risks are reduced. Where joints are required, the system must be sized to accommodate the anticipated movement. Manufacturers publish movement capabilities, usually as a percentage of their relaxed dimension, but joints rarely compress to zero. This requires careful coordination between the structural engineer, architect, and product manufacturer.

Occupancy and Risk Levels

The use of the space adjacent to a below-grade expansion joint should also inform the waterproofing approach.

  • Lower-risk spaces (e.g., parking garages, utility rooms): cost-effective waterproofing may be acceptable.

  • Higher-risk spaces (e.g., labs, data centers, operating rooms, or storage areas for sensitive materials): require robust, redundant systems and possibly relocation away from the joint.

By understanding occupancy risk, project teams can align waterproofing investments with performance expectations.

Construction Methods: Positive-Side, Blind-Side, and Negative-Side

Waterproofing installation methods greatly influence system performance. Three common approaches are:

  • Positive-side waterproofing. Installed after concrete placement, on the exterior surface. Offers the best access for surface preparation, detailing, and inspection, but requires over-excavation.

  • Blind-side waterproofing. Installed against shoring before concrete is placed. Common in zero-lot-line projects. Difficult to access for repair, and reliant on proper concrete consolidation and formwork stability.

  • Negative-side waterproofing. Installed on the interior face of the foundation. Offers better control than blind-side but requires careful detailing to tie the expansion joint system into adjacent membranes.

Each approach requires different detailing and product selection. Early coordination between contractors, waterproofing installers, and design teams is essential. Preconstruction meetings, QA/QC inspections, and experienced subcontractors reduce the risk of failures during installation.

Expansion Joint System Options

Expansion joint systems (EJS) are the first line of defense against below-grade water intrusion. Unlike joint fillers, which are not watertight, EJS products must integrate with surrounding waterproofing membranes. Common options include:

Sheet Membrane Bellows

Made from strips of sheet waterproofing membrane, these joints are cost-effective and field-fabricated. However, they lack published performance data, have limited movement capacity, and are prone to field splice failures. Best suited for low-risk conditions above the water table.

Vulcanized Rubber EJS

Factory-fabricated rolls of vulcanized rubber with reinforced flanges. Highly flexible, nearly 100% compressible, and reliable for long-term waterproofing. Installation requires precise field measurements and can delay projects if adjustments are needed. Works best for positive- or negative-side applications.

Thermoplastic EJS

Extruded thermoplastic membranes designed specifically for blind-side applications. They provide strong hydrostatic resistance and can be hot-air welded to adjacent thermoplastic membranes. Factory welds are more reliable than field welds, but limited tolerance can complicate installation.

Clamped Reinforced Rubber EJS

The most robust option, featuring fabric-reinforced rubber clamped to the structure with steel plates. Ideal for tunnels, hospitals, transit facilities, and other high-risk infrastructure projects. Highly durable but expensive, with long lead times and custom detailing requirements.

When selecting a system, evaluate movement capability, hydrostatic resistance, durability, ease of integration with adjacent waterproofing, and long-term maintenance considerations.

Secondary Expansion Joint Waterproofing Options

For high-risk occupancies or critical infrastructure, redundant systems provide an added layer of protection. Secondary strategies include:

  • Installing two EJS systems in series.

  • Using compressible foam joints designed for buried conditions.

  • Injecting chemical grout into reinforcing foam blocks.

  • Integrating PVC waterstops with thermoplastic membranes.

  • Installing foundation drainage systems tied to sump pumps or stormwater connections.

  • Designing interior leakage collection troughs connected to sump pumps or electronic monitoring.

These systems should not replace the primary joint system but can mitigate leakage if the primary system fails.

Troubleshooting and Long-Term Maintenance

No below-grade system can guarantee a zero-leakage service life. Seasonal groundwater fluctuations, construction damage, and structural movement all present long-term risks to the waterproofing performance. Best practices include:

  • Planning for remedial grout injection or interior waterproofing.

  • Leaving unfinished interiors where possible for easier access.

  • Adding interior leakage collection in high-risk occupancies.

Conclusion: Best Practices for AEC Professionals

For architects, engineers, and contractors, success in below-grade expansion joint waterproofing comes down to four key practices:

  • Design: Assess groundwater, soil pressures, structural movement, and occupancy use. Eliminate unnecessary joints where possible.

  • Construction: Coordinate with all trades, choose the right products for the project’s construction means and methods, and require qualified waterproofing subcontractors in combination with QA/QC inspections.

  • Product Selection: Match EJS products to site conditions and occupancies, and consider systems with a strong performance track record and comprehensive manufacturer support.

  • Redundancy and Maintenance: Add secondary systems for critical facilities and plan for the detection of future leaks and repairs.

Successful below-grade expansion joint waterproofing requires coordinated input across disciplines. With clear design parameters and collaboration, AEC professionals can minimize risk and deliver durable solutions for below-grade spaces.
